LDT114-C012UC
Economy Armored Mechanical Spring Monitor Arm with USB-A & USB-C Ports
In stylish appearance to fuel the vibe.
Designed for gaming, the LDT114-C012UC brings style and performance together. With bold color options and futuristic shapes, an advanced gameplay vibe is created for stronger immersion. Full flexibility—tilt, swivel, and rotation—polishes every angle for optimized viewing, while the built-in spring tension mechanism ensures smooth, effortless adjustments. A keyhole-patterned VESA plate makes setup and disassembly effortless, and a base with USB ports facilitates charging and data transfer.
Color:
Matte White
Matte Black
Matte White & Blue
- Various Color Options: satisfy different personal preference or home decor
- Wide Range of Movements: allows screen tilting, swiveling, rotation and height adjustments for optimum viewing
- Built-in Spring Tension Mechanism: for perfect weight adjustments
- Keyhole Pattern: allows for easy installation
- Smart Base with USB-A & USB-C Ports: snap-off plates on the base provide data throughput or to charge devices
- SPECIFICATIONS
- BROCHURE
Product Category |
Mechanical Spring Monitor Arm |
Rank |
Standard |
Material |
Aluminum,Steel,Plastic |
Surface Finish |
Powder Coating |
Color |
Matte White,Matte Black |
Dimensions |
120x508x587mm (4.7"x20"x23.1") |
Fit Screen Size |
17"-40" |
Fit Curved Monitor |
Yes |
Screen Quantity |
1 |
Weight Capacity (per screen) |
2~12kg (4.4~26.4lbs) |
Weight Capacity for Curved Screen (per screen) |
2-11kg (4.4lbs-24.2lbs) |
VESA Compatible |
75x75,100x100 |
Tilt Range |
+80°~-45° |
Swivel Range |
+90°~-90° |
Screen Rotation |
+180°~-180° |
Arm Full Extension |
455mm (17.9") |
Installation |
Clamp,Grommet |
Suggested Desktop Thickness |
Clamp:10~80mm Grommet:10~40mm (Clamp:0.39"~3.1" Grommet:0.39"~1.6") |
Quick Release VESA Plate |
No |
USB Port |
1xUSB 3.0 Port,1xTYPE-C |
Cable Management |
Yes |
Accessory Kit Package |
Normal/Ziplock Polybag |
Silk Screen |
Can be silkscreen printed |
